casals
HM EVO EEC
LONG CASE VARIABLE PITCH BLADES WITH EEC MOTOR
Specifications
MANUFACTURING FEATURES • Long case axial fan with reinforced body, with double flange, made of rolling steel sheet. • Pad mounted motor support system with guide vanes. • Polyester powder finishing coat. • Low sound level and high performance. • PM brushless motor (permanent magnets), synchronous, electronically commutated, high efficiency and low sound level. Specially designed for fans with electronic operation and control in deported box IP65. Working range: from 400 to 1200-2000rpm (depending on the models) Motor with IP54 protection and class F insulation. IP 65 drive case Power: 220V ± 10% single phase Power frequency: 50 / 60Hz Operating temperature range: -20ºC to 50ºC Speed control through signal 0-10V or PWM • Polypropylene impeller with variable pich angle (Stopped and in origin). APPLICATIONS Designed for inline installation, they are suitable for: • Air renewal in buildings and industries. • Smoke extraction. • Maximum working temperature 60ºC. UNDER REQUEST • Casing in hot galvanized sheet or stainless steel.
